USB Module
Module(Ethernet Bridge)
specification
|
Item
|
Spec / Feature
|
Remarks
|
|
Frequency , Band Width
|
2.4Ghz ~2.485Ghz, 8Mhz/16Mhz
|
|
|
Data Rate
|
Max 55Mbps (physical layer)
|
|
|
Max Out Power
|
Max 19dbm
|
|
|
Transmission distance
|
Max 800m
|
5dbi Dipole Ant
|
|
No of Channel
|
5 /11 Ch
|
22/44Mhz Mode
|
|
Interface
|
RJ-45 |
Ethernet |
|
Input Power
|
3.3v |
|
|
Protolcol |
Embed UDP/IP, ARP
|
Windodws, Linux |
